X-RIDER
R590 LOGO RED.png
REVISED R590 MODEL png.png

INDICATIVE PRICE RANGE*

$65k - 75k BMT

*Provided as a guide only. Price may vary depending upon dealer packaging, statutory costs and freight.

ALSO CONSIDER:

5.90

Length

m

m

2.40

Beam

lt

kg

1800

200

hp

7

People

130

Fuel

Power

Tow Weight

adults



The R590 X-Rider is a rebel with a cause. Svelte in profile, this beamy all-rounder was conceived with one purpose in mind: to be the only boat an adventurous boating family would

ever need. Period!

No matter what's on your family's boating agenda, the new R590 X-Rider delivers

The new R590 X-Rider breaks with conventional boating rules and writes a few new ones in the process. Building on the bowrider concept, the twin console X-Rider distills the essence of a family day boat and stirs in equal parts ski boat and sportfisher for the ultimate boating cocktail. A wave-slicing 21degree deadrise dictates a soft rides while the broad reverse chines ensure stability at rest and uncompromised handling at all speeds. A deep, spacious rear cockpit will accomodate all your crew or remove the rear storage seats to reveal a fishing cockpit that'll fish four sat a time. Thrill seekers can brace themselves in the bow pews when the captain ignites the throttle or slide in the optional casting platform insert and convert the forward zone into a casting deck for a couple of eager lure chuckers. There's underfloor storage to swallow a big day's catch or a  family-load of gear as well as a hidden rod/ski locker and provision for an optional fridge...and that's just the start!

     All-new Composite Fibreglass stringer system.

     Redesigned helm accommodates up to 16" head units.

     Efficient hull design maximises performance without compromising on ride comfort       or stability at rest.

     Unrivalled storage options to hide skis, fishing tackle and family gear.

     New X-Rider re-write's the bowrider rule book, and creates a few rules of its own.

R590 outboard options

A hallmark of all Revival hulls is an efficient hull design that doesn't compromise on ride quality or stability. Ideally powered by 4-Stroke or DI (Direct Injection) outboards in the 135 - 150hp range, the R590 will provide ample performance even with with smaller torque-rich engines such as Mercury's 115 PRO XS CT 4-stroke.

115

200hp

Towabililty

The R590 X-Rider has a combined towing weight of around 1800 -1900kg which puts it well within the scope of any SUV, ute or wagon with a tow-rating of at least 2-tonne. Porsche's sporty Macan is one of many compact tow tugs that are up to the task.

1800kg*

*Nominal R590 X-Rider BMT dry towing  weight
*2017 Porsche Macan S Diesel..2400kg braked towing capacity



R590 IN MOTION

Check out the R590 strutting its considerable stuff. Every bit the consummate all-rounder, the R590 delivers versatile space well beyond what it's compact dimensions might suggest while the ride-quality in challenging conditions needs to be experienced.

Full 590 X-Rider Vic Fishing Monthly Video Review

(Courtesy Steve Morgan, Fishing Monthly)



COLOUR and TRIM*

All Revival hulls are available in the standard Arctic White gelcoat or splash out with one of eight (8) full or two-tone gelcoat options. SportZ and OffShore editions feature two-tone grey vinyl interiors while WeekEnders are treated to cloth detailing in the cabins.



Colour plays an important part in our daily lives.  It reflects our mood, shows our allegiances and camouflages us within our environment. Colour is nature's mechanism for blending in or standing out. What colour are you?



Gelcoat Hull Side Two-Tone Colour (narrow plank)*



ARCTIC WHITE

(STANDARD)

WARM GULL GREY

CHARCOAL

HERMITAGE RED

OXFORD BLUE

POWDER BLUE

JET BLACK

APPLIED RED

EXTERIOR

Gelcoat Hull Full-Side Colours (chine to gunnel)*



ARCTIC WHITE

(STANDARD)

WARM GULL GREY

CHARCOAL

HERMITAGE RED

APPLIED RED

OXFORD BLUE

POWDER BLUE

JET BLACK

INTERIOR

Marine Carpet

(Standard)

Simulated Teak

(Optional)

*Colours depicted are digital approximations of the actual gel-coat colours and should serve  guide only.  Please review actual colour samples with your authorised Revival Boats dealer.

TECH SPEC and FEATURES

Despite its garage-friendly dimensions, the R590 boasts one of the most versatile rear cockpits in its class. A wave-slicing 21deg deadrise  ensures a soft, dry ride while the broad stance creates a stable and confident platform at rest and underway.

R590 X-RIDER FEATURES


  • Anchor Storage Compartment with Large Front Opening Hatch
  • Bilge Pump Hose and Outlet
  • Bollard Split - Stainless Steel
  • Bow Rider Cushions and Upholstered BackRests with Upholstered Storage Pockets
  • Bow Roller - Stainless Steel
  • Carpeted Floor - Deluxe. Shaped with Edging
  • Cockpit Lights (2)
  • Cockpit Side Pockets - Fibreglass Gelcoated White with Vinyl Trim
  • Composite Fibreglass Stringer System Moulded Liner
  • Console Side Storage Lockers
  • Drink Holders - Stainless Steel x 4
  • Glove Box - Large Fully-Carpeted
  • Hydraulic Steering with Sports Steering Wheel
  • Hull and Deck - All White Gelcoat with Edition Specific Stripes and Graphics
  • Large Forward Storage/Casting Area with Open and Concealed Storage Bins
  • Large Lockable Ski/Rod Locker
  • Navigation Lights
  • Padded transom Backrest Rear of Cockpit with Storage-Style Rear Lounge
  • Padded Side Pockets - Vinyl Detailing
  • Panic Rail for Passenger - Stainless Steel
  • Port-side Coaming Storage Compartment
  • Rear Starboard-Side Storage Locker/Bait Well that Drains Overboard - Not Plumbed
  • Rear Pop-Up Cleats - Stainless Steel (2)
  • Rear Door/Step Through
  • Rear Tow Eyes - Stainless Steel (2)
  • Swivel Bucket Seats on Fixed Pedestals with Seat Slides and Flip Up Bolsters
  • Twin-Core Tinned Wiring to Dash
  • Underfloor Fuel Tank 130L with Breathers that Drain to Engine Well, Fuel Sender, Filler Cap in Engine Well
  • Underfloor Kill Tank/ Storage Locker - Moulded Fibreglass (Aprox 200lt)
  • Water-Resistant Switch Panel - Slimline Deluxe Metal Finish




OPTIONAL ACCESSORIES


Electrical:

  • Upgrade Bilge Pump to Auto with Float Switch
  • Twin Battery System Upgrade
  • Electric Anchor Winch - Pre Install and Fit Hawse Pipe
  • Electric Anchor Winch - Complete Installation
  • 27Mhz Radio and Antenna Installation
  • VHF Radio and Antenna Installation
  • Fusion Marine Sound System (Quote Upon Request)
  • 12-Volt Socket Installation (Each)
  • 12-Volt USB Installation (Each)
  • Live Bait Well Plumbing (Each)
  • Plumbed Deck Wash
  • Concealed LED Strip Lights x 2
  • LED Spotlights off Rocket Launcher x 2
  • LED Cabin Light
  • Fish Finder/GPS Installation (Quote Upon Request)
Hydraulic Steering:
  • Sea Star Hydraulic Helm and Ram Standard
Deck Fittings:
  • Stainless Steel Rod Holders
  • Rope Mooring Cleats - Stainless Steel
  • Pop-Up Cleats - Stainless Steel
  • Fender Holders (Retractable)




DIMENSIONS


Hull Length (mm)... 5900mm Hull Beam (mm)... 2400mm Transom Deadrise... 21 degrees Transom Height (inches)... 25"/XL Height on Trailer to top of Windscreen... 2450mm Overall Length on Trailer (mm)... 7200mm Draft (mm)... 300mm Hull Weight (kg) - dry... 950kg BMT Weight (kg) - dry... 1800kg* (Subject to variation) Fuel Capacity (lt)... 130lt Number of People... 7 Adults Horsepower... 115 - 200hp Max Outboard Weight (kg)... 250kg Estimated Cruise Speed (kph) w/Mid-Range hp... 45kph Estimated WOT Speed (kph) w/Mid-Range hp... 75kph (150HP) Internal Cockpit Length (mm)... 1600mm Internal Cockpit Beam (mm)... 1950mm




OPTIONAL COVERS AND CONVENIENCE


High Quality Marine Grade Fabric:

  • Covers: Bimini, Folds Down into Cockpit
  • Covers: Bimini Extension
  • Covers: Zippered panel in Bimini Extension
  • Covers: Front and Side Clears
  • Covers: Zippered Panel in Front Clears (Each)
  • Covers: Tonneau Travel Cover
  • Covers: Tonneau Travel Cover over Windscreen
  • Covers: Camper Back with Removable Panels
  • Covers: Cabin Divider
  • Covers: Flyscreen Mesh Panels to Cabin Divider
  • Covers: Flyscreen Mesh Panels to Camper Back
  • Covers: Custom-Fitted Bag Storage/Travel Cover
  • Folding Rocket Launcher - Alloy
  • Folding Rocket Launcher - Stainless Steel
Seating and Convenience:
  • Delete Carpet and Replace with RevivalTread Non-Skid and Alloy Trim Strips
  • Dinette Table - Removable
  • Front Carpeted Casting Platform Infill
  • Gas Assist Seat Pedestals (Each)
  • Height Adjustable Seat Pedestals (Each)
  • Moulded Fibreglass Seat Storage Boxes (Each)
  • Padded Side Coamings - Vinyl Upholstery
  • Rear Seat Storage Boxes with Wrap Around Backrest
  • Roll-Over Adjustable Seat Bases - Stainless Steel
  • Slip-Resistant Simulated Teak Rubber Flooring System
  • Stainless Steel Rear Platform and Boarding Rails
  • Stainless Steel Rear Boarding Ladder
  • Stainless Steel Boarding Ladder and Rails (No Boarding Platforms)
  • Stainless Steel Ski Pole - Removable with Floor Mount







NOTABLE FEATURES*

Every Revival comes pre-loaded with standard features many of our competitors consider to be options. SportZ, OffShore and Weekender grades vary in the level of fit-out and can be further enhanced with additional factory-installed options and accessories.

25" TRANSOM FOR

ADDED SAFETY & PERFORMANCE

Exterior Features

Revival firmly believes in a  "what you see is what you get" approach to boat design and packaging. We load our boats to the gunnels with standard features many of our competitors list as options yet offer plenty of scope for personalising your craft to reflect your boating desires. Uncompromising yet versatile boats tailored with YOU in mind.

Interior Features

Fact: you'll spend much longer at rest than driving to and from your destination, so its super important that every Revival interior reflects its intended purpose. Boasting unrivalled storage options for all your gear, Revival strives for uncluttered spaces to fish or socialise. At the end of the day, simply hose out and head home. Boat. Wash. Repeat!

LARGE DASH  MEANS IT'LL FIT LARGE HEAD UNITS

LOWRANCE FISHFINDERS & GPS CHARTPLOTTERS

Optional Equipment

Half the fun of owning a boat is personalising it to reflect your boating personality. Whether its for convenience, functionality or simply "bling' factor, Revival offers an extensive array of options and accessories sure to make your boating mates green with envy. What's more, our stream-lined interiors make customisation at any stage a breeze.
